Description
iSMA Graphics is a comprehensive high-quality graphics library designed for HVAC and building automation visualization within the Niagara Framework environment. It provides both 2D and 3D graphical libraries that enable clear, modern, and intuitive representation of building systems, equipment, and processes.
The library is designed to simplify and accelerate the creation of system visualizations by offering a wide range of pre-built graphical widgets and templates for common HVAC applications such as AHU, RTU, VAV, and FCU systems, as well as lighting, metering, pumps, and other building automation components.iSMA Graphics delivers a modern, consistent visual language that improves system readability and operator experience. The 3D library provides detailed, animated plant representations, while the 2D library focuses on clear, easy-to-read schematic visualizations.
Both Graphic packages are pre-licenses for MAC36PRO controllers and are available for any Niagara 4-based systems.
Key Features
Comprehensive 2D and 3D graphics libraries for HVAC and building automation systems
Designed for Niagara 4
Pre-licensed for MAC36PRO controllers (included with devices)Wide range of HVAC, lighting, metering, and plant equipment graphics
Over 300 high-quality 3D graphical plant and device representations
Modern 2D schematic graphics available in blackline and whiteline styles
Predefined templates for AHU, RTU, VAV, and FCU applications
Intuitive, modern, and consistent design for improved system readability
Animated and multistate visualization using color and position changes
Demo station with real-world application examples for faster engineering
Optimized for fast visualization development and deployment within Niagara projects
